Hydraulic flange hi a rit zawng-duty, high-Pressure connection component a sang a, hydraulic system-a secure leh leak-free fluid transfer atana siam a ni. SAE J518 leh ISO 6162 standards zawm tura engineered, he flange hian industrial, mobile, leh stationary hydraulic application mamawh tak takah rintlak taka performance a siam a ni.
Specifications 1.1.
|
part no. |
flange size 1000 a ni. |
Hose Bore 1000 a ni. |
Dimension hrang hrang . |
|||||
|
DN 10 a ni. |
THEH |
A |
C |
D |
H |
L |
||
|
87341-08-08 |
1/2" |
12 |
08 |
58.2 |
30.2 |
24 |
23.3 |
6.73 |
|
87341-12-08 |
3/4" |
12 |
08 |
58.9 |
38.1 |
31.7 |
24 |
6.73 |
|
87341-12-10 |
3/4" |
16 |
10 |
70.1 |
38.1 |
31.7 |
25.3 |
6.73 |
|
87341-12-12 |
3/4" |
20 |
12 |
77 |
38.1 |
31.7 |
28.9 |
6.73 |
|
87341-16-12 |
1" |
20 |
12 |
77 |
44.4 |
38 |
28.9 |
8 |
|
87341-16-16 |
1" |
25 |
16 |
85.2 |
44.4 |
38 |
29.7 |
8 |
|
87341-16-20 |
1" |
32 |
20 |
94.5 |
44.4 |
38 |
33.8 |
8 |
|
87341-20-16 |
1.1/4" |
25 |
16 |
85.2 |
50.8 |
43 |
29.7 |
8 |
|
87341-20-20 |
1.1/4" |
32 |
20 |
94.5 |
50.8 |
43 |
33.8 |
8 |
|
87341-24-20 |
1.1/2" |
32 |
20 |
95.9 |
60.3 |
50 |
35.2 |
8 |
|
87341-24-24 |
1.1/2" |
40 |
24 |
109.9 |
60.3 |
50 |
39.1 |
8 |
|
87341-32-24 |
2" |
40 |
24 |
109.9 |
71.4 |
62 |
39.1 |
9.53 |
|
87341-32-32 |
2" |
50 |
32 |
129.3 |
71.4 |
62 |
46.3 |
9.53 |
Parameters/technical data a awm em?
|
Dik tak |
China ram Zhejiang-ah chuan a awm a. |
Delivery hun tur . |
Negotiable theih a ni . |
|
Certification 1000 a ni. |
GB/T19001-2016 IDT ISO9001:2015 ah hian a awm a. |
Packing a awm em . |
Export standard 100 a ni. |
|
Bungrua |
Carbon steel 1000 a ni. |
Warranty a awm em? |
Kum 1 . |
|
Pawisa pek hun tur . |
TT 10 a ni. |
MOQ 10 a ni. |
2000 |
|
Dinhmun |
Thar |
Rawng |
A rilru a buai em em a, a rilru a hah em em bawk a. |
Company chungchang .
A thatna te .
A chhe thei lo .
High-Grade forged steel atanga siam chhuah, precision machining hmanga siam a ni.
Optional 316 stainless steel a awm a, a hmun pawh a chhe thei hle.
Industry standard flanges nena khaikhin chuan service life 3x a rei zawk.
Pressure performance tha zawk a awm bawk.
10,000 psi burst pressure 10,000 thleng tuar thei tura test a ni.
Pressure inthlak danglamna nasa tak hnuaiah seal integrity a vawng reng a ni.
100% pressure test hmain test a ni.
Engineering tih hi a ni a, a pawimawh hle.
CNC chu ±0.01mm tolerance thlenga machine hmanga siam a ni a, a fit tha ber a ni.
Laser-a traceability atan identification marks etched a awm bawk.
Optimized flow design hian turbulence a ti tlem hle.
Leak-proof guarantee a awm lo.
Proprietary triple-Seal Technology .
Micro-sealing surface zawh tawh (Ra < 0.8μm) a ni.
High-Performance HNBR O-RINGS chu standard angin a huam tel bawk.
Khawvel pum huapa zawm .
SAE J518, ISO 6162, leh DIN Standards te chu certified a ni.
Mill Test Certificate hmanga Material Traceability kimchang .
Reach leh ROHS compliant .
Installation a thatna te .
Color-Pressure rating hmanga lak chhuah a ni a, awlsam taka hriat theih a ni.
Pre-Assembled bolt kits te chu a awm a.
Competitor products aiin 30% in installation a chak zawk
Customization theihna .
Size 1/4" atanga 4" thleng a awm bawk.
Duplex steel leh titanium te bakah thil bik
Custom port configuration leh bolt pattern te a awm bawk.
Nun chhunga Technical lama puihna .
Engineering support team inpekna nei tak an ni.
Free System nena inmil theihna tur check .
On-Site installation training neih theih a ni.
Industry-Leading warranty a awm.
Kum 5 chhung atan limited warranty a awm a.
Thla 24 chhunga corrosion laka invenna tur guarantee .
NO-Zawhna-Hrehawm thlak dan tur zawhfiah rawh .
Khawvel pum huap logistics network 1000 a ni.
ISO-Khawvel puma thil siamna hmun certified te .
Same-Standard thila ni khat thawn chhuah
International shipment atana documentation package kimchang .
FAQ a ni.
Q: Eng pressure rating nge awm?
A: Standard pressure ratings te chu:
3000 psi (207 bar) a ni.
6000 psi (414 bar) a ni.
Design bik 10,000 psi (690 bar) thleng a awm thei
Q: Eng material nge i pek thin?
A: Standard materials: 1.1.
Carbon steel leh zinc plating a awm bawk.
304/316 a ni a, a rimtui hle.
Thil pawimawh bik:
Duplex stainless steel a ni.
Titanium alloy te pawh a awm bawk.
Nickel- siam alloy a ni.
Q: Engtin nge flange size dik tak ka thlan ang?
A: Thil pawimawh thlan tur:
Hose chhung lam diameter (ID) .
System hnathawh pressure .
Flow mamawhna .
Environment dinhmun .
Kan technical team te hian a thlawna sizing assistance an pe thin.
Q: Eng sealing method nge awm?
A: Sealing option hrang hrangte chu:
O-Ring hmai seal (Orfs) .
Flat face leh gasket a awm bawk.
spiral wound gasket hmanga hmai sang tak a ni.
Metal-to-Metal seal a ni.
Q: I flanges te hi brand dang nen an inthlak danglam thei em?
A: Ni e, kan flanges te hi SAE/ISO compliant flanges dang nena inthlak danglam theih tura siam a ni. Critical application atana dimensions verify turin kan rawt a ni.
Q: Custom flanges atana i lead time chu eng nge ni?
A: Standard lead hun:
Stock Items: Ni 1-3 chhung
Standard Custom: Kar 2-3 chhung
Thil hman tur bik/Designs: Kar 4-6 chhung
Expedited services a awm bawk.
Q: Installation instruction i pe em?
A: Ni e, kan pe a:
Step-by-Step Installation hmanga siam a ni.
Torque Specifications 1.1.
Seal lubrication rawtna siam .
Video tutorials dil theih a ni
Q: Eng certification nge i neih?
A: Kan certification-ah hian:
ISO 9001:2015 ah a awm a.
PED 2014/68/EU ah a awm a.
ATEX (Bognsive Environment atan) .
ABS Marine phalna lak a ni.
Q: Engtin nge hydraulic flanges hi ka enkawl ang?
A: Enkawlna atana rawtna: 1.1.
Kum tin hmuh theiha enfiahna .
Torque hian darkar 500 danah a check thin .
Kum 2 danah seal thlak thin .
Kum 5 emaw darkar 20,000 emaw hnuah a thlakna tur kimchang
Q: I warranty policy chu eng nge ni?
A: Kan offer a:
Kum 5 chhung atan Limited Warranty chu Materials/Hnathawktute tan a ni.
Kum 2 chhunga performance guarantee a awm bawk.
Kum 1 chhung seal integrity warranty a awm a.
Warranty hian install leh hman dan tur dik tak a mamawh a ni.
hot tags .: Hydraulic flange, China Hydraulic Flange siamtute, Factory
